JD748B, JD788B Product no: 566

CellAdvisor Signal Analyzers JD748B, JD788B

CellAdvisor Signal Analyzer combines the functionality of spectrum analysis, DAS, and power measurements, covering all of your needs for base station troubleshooting and maintenance.





CellAdvisor Signal Analyzers support RFoCPRI and NB-IoT testing, and offer spectrum / interference / signal demodulation and RF / optical power meters and optional fiber inspection in a rugged, portable cloud-enabled instrument.

JD748B JD788AB
Spectrum Analyzer​ 100 kHz to 4 GHz​ 9 kHz to 8 GHz​
Power Meter​ 10 MHz to 4 GHz​ 10 Mhz to 8 GHz​

The CellAdvisor Signal Analyzers have a rugged enclosure design for harsh environments and a backlit key panel for night-time and low-light performance.



  • Easy to upgrade and future-proof
  • Multiple functions in one platform
  • LTE-A Carrier Aggregation
  • LTE Automeasure
  • MIMO 4X4
  • Multimedia Broadcast Multicast Service Analysis
  • PIM Detect
  • RF measurement over CPRI
  • Dual Spectrum View
  • Ensure signal quality to guarantee value added services
  • One‐button standards-based measurements for wireless signals

  • Capable of demodulation of all wireless technologies up to LTE
  • Easy to use Auto-Measure function presenting RF and Modulation analysis in a summary screen
  • Fiber Inspection
  • Interference Analysis and PIM detection over CPRI
  • Fronthaul and RRH verification over CPRI

  • Spectrum Analyzer up to 8 GHz
  • Signal Analyzer for all wireless technologies from 2 G to 4 G
  • LTE-A Carrier Aggregation
  • MIMO 4X4
  • PIM Detect
  • Multimedia Broadcast Multicast Service Analysis
  • Layer-2 term & monitoring for CPRI fronthaul
  • Interference Analysis over CPRI fronthaul
  • PIM Detection over CPRI fronthaul
  • Dual Spectrogram View
  • Interference Analyzer
  • Channel Scanner
  • RF Power Meter (internal and external)
  • Over-the-Air Measurement (OTA)
  • Bluetooth remote control within 100M
  • Cloud enabled via VIAVI StrataSync
  • Unique Optical Power Meter (with appropriate USB accessory)
  • Fiber Inspection via P5000i microscope
